| Specifications | : | ASTM B564 / ASME SB564 |
| Size | : | 1/2" NB TO 60" NB |
| Standards |
: | ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc. |
| Class / Pressure | : | 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc. |
| Standard | : | ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc. |
Slip on Flanges
- Incoloy 800H / 800HT Slip on Flanges
- Incoloy 800H / 800HT Raised Face Slip on Flange
- ASTM A182 RFSO Flange
Lap Joint Flanges
- Incoloy 800H / 800HT Lap Joint Flanges
- Incoloy 800H / 800HT Lapped Joint Flanges
- ASTM A182 Lapped Joint Flange
Weld Neck Flanges
- Incoloy 800H / 800HT Weld Neck Flanges
- Incoloy 800H / 800HT Welding Neck Flanges
- ASTM A182 RFWN Flange
Blind Flanges
- Incoloy 800H / 800HT Blind Flanges
- Incoloy 800H / 800HT BLFF Flange
- ANSI B16.5 BLRF Flange
Orifice Flanges
- Incoloy 800H / 800HT Orifice Flanges
- Incoloy 800H / 800HT Raised Face Orifice Flange
- ASTM A182 Orifice Flange
Plate Flanges
- Incoloy 800H / 800HT Class 150 Plate Flanges
- Incoloy 800H / 800HT Flat Flange
- ANSI B16.5 Plate Flange
Socket Weld Flanges
- Incoloy 800H / 800HT Socket Weld Flanges
- Incoloy 800H / 800HT SWRTJ Flanges
- ANSI B16.5 Socket Weld Flange
Threaded Flanges
- Incoloy 800H / 800HT Threaded Flanges
- Incoloy 800H / 800HT Threaded Flanges
- ANSI B16.5 Threaded Flanges
Ring Type Joint Flanges
- Incoloy 800H / 800HT Ring Type Joint Flanges
- Incoloy 800H / 800HT RTJ Flanges
- ANSI B16.5 Raised Face Ring Flanges
Long Weld Flanges
- Incoloy 800H / 800HT Long Weld Neck Flanges
- Incoloy 800H / 800HT Long Welding Neck Flanges
- ANSI B16.5 Long Weld Neck Flange
Spectacle Blind Flanges
- Incoloy 800H / 800HT Spectacle Blind Flanges
- Incoloy 800H / 800HT Spacer Blind Flange
- ANSI B16.5 Spectacle Blind Flange
Groove & Tongue Flanges
- Incoloy 800H / 800HT Groove & Tongue Flanges
- Incoloy 800H / 800HT Tongue & Groove Flanges
- ANSI B16.5 Groove & Tongue Flange
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN | OR |
| Incoloy 800H | 1.4958 / 1.4876 | N08810 | NCF 800H | NA 15(H) | ??670 | Z8NC33-21 | X5NiCrAlTi31-20 | XH32T |
| Incoloy 800HT | 1.4859 / 1.4876 | N08811 | NCF 800HT | NA 15(HT) | ??670 | – | X8NiCrAlTi32-21 | XH32T |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| 800H | 0.05 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| 800HT | 0.06 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60? | 0.15 – 0.60? |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Incoloy 800H / 800HT | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
| Price List | |
| Incoloy 800H / 800HT Flanges | US / Metric Ton (FOB Price) on request |
| Incoloy 800H / 800HT Flanges | US / Metric Ton (FOB Price) on request |
| Incoloy 800H / 800HT Flanges | US / Metric Ton (FOB Price) on request |
| Incoloy 800H / 800HT Flanges | US / Metric Ton (FOB Price) on request |
| Preview | Products | ASTM | ASME |
|---|---|---|---|
 |
Incoloy 800H / 800HT SORF Flange | A182 SORF Flange | SA182 SORF Flange |
 |
Incoloy 800H / 800HT WNRF Flange | A182 WNRF Flange | SA182 WNRF Flange |
 |
Incoloy 800H / 800HT SWRF Flange | A182 SWRF Flange | SA182 SWRF Flange |
 |
Incoloy 800H / 800HT BLRF Flange | A182 BLRF Flange | SA182 BLRF Flange |
 |
Incoloy 800H / 800HT RTJ Flange | A182 RTJ Flange | SA182 RTJ Flange |
| American Steel Flanges Standard | |
| Standard Code | Standard Name |
| ANSI ASME SA-182 | Forged Flanges |
| ANSI ASME B16.5 | Slip on flange, Welding neck flange, Blind flange, Threaded flange, Lap joint flange, RTJ flange |
| ASME – B 16.47 | Welding neck flange, Blind flange |
| ASME – B 16.36 | Welding neck flange Slip on flange |
